Fiber Cement Board Exterior Cladding Systems

Fiber Cement Board Exterior Cladding Systems comprise three core components: Façade Panels / Rainscreen Cladding for primary weather protection, Soffit Panels for under-eave ventilation, and Decorative Shingles for aesthetic enhancement.

Engineered facade panels combining durability, weather resistance, and design flexibility. Ideal for ventilated rainscreen systems.

Key Advantages:
1.Weather Resistance

  • Rainscreen design prevents moisture buildup

  • Hydrophobic coatings (water absorption ≤10%)

  • Suitable for coastal/humid climates

2.Fire Safety

  • Class A non-combustible (ASTM E136 / EN 13501-1)

  • Cement matrix delays fire spread

3.Design Versatility

  • Mimics wood/stone/metal textures

  • Custom colors & curved facades (min. radius: 12m)

4.Sustainability

  • 20–30% energy loss reduction with insulation

  • Recycled materials, zero VOC emissions

5.Installation Efficiency

  • Lightweight (10–24 kg/m²)

  • Compatible with metal/wood substructures

Technical Parameters Table

CategorySpecificationsCertification
MaterialPortland cement (80%) + cellulose/sandASTM C1186, EN 12467
DimensionsL: 1,200–3,600 mm
W: 455–1,500 mm
T: 6–35 mm		Custom up to 6,000 mm
Surface Options• Primed/painted (UV-resistant)
• Woodgrain/stone texture
• Polished or raw		Ceramic top layers (JP)
Key Properties• Density: 1,400–1,800 kg/m³
• Bending strength: 15–30 MPa
• Thermal conductivity: ≤0.20 W/m·K
• Frost cycles: 100+
• Fire rating: Class A		ISO 8335, SANS 803
Installation• Joints: Open (8–12mm)/overlapped
• Fixing: Screws or concealed clips
• Substructure: Steel/wood @ 30–60cm spacing		Ventilation gap ≥40 mm

Regional Application Notes

• Europe: Bold 3D textures (e.g. Equitone Linea)
• Japan: Narrow wood-plank styles (e.g. Nichiha 455×3030mm)
• Seismic Zones: Use ≤14 kg/m² panels (8mm thickness)

Lifecycle: 20–50 years with minimal maintenance
